Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring

Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring

Tempat asal:

Guangdong, Tiongkok

Nama merek:

Hilink

Sertifikasi:

CE RoHs

Nomor model:

HL-QDD-400G-SR8

Hubungi Kami
Minta Kutipan
Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring
Rincian produk
Nama Produk:
QDD-400G-SR8
Kecepatan Data:
400G
Jarak:
100m
Jaminan:
3 tahun
Sertifikasi:
RoHS
Waktu Pengiriman:
3-7 hari kerja
OEM:
Mendukung
Syarat Pembayaran & Pengiriman
Kuantitas min Order
1 buah
Harga
120~130USD/UNIT
Kemasan rincian
Paket Normal Atau OEM
Waktu pengiriman
5-8 hari kerja
Syarat-syarat pembayaran
L/C,T/T,Western Union
Produk terkait
Harga yang bagus Hilink QSFP56-200G-SR4 Multi-mode 850nm 200G BASE-SR4 QSFP56 Transceiver With Diagnostic Monitoring on line

Hilink QSFP56-200G-SR4 Multi-mode 850nm 200G BASE-SR4 QSFP56 Transceiver With Diagnostic Monitoring

Dapatkan Harga Terbaik
Harga yang bagus Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring on line

Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring

Dapatkan Harga Terbaik
Harga yang bagus QDD-400G-SR8 400G MMF 850nm QSFP-DD PAM4 100m DOM MTP/MPO-16 Transceiver Optik on line Video

QDD-400G-SR8 400G MMF 850nm QSFP-DD PAM4 100m DOM MTP/MPO-16 Transceiver Optik

Dapatkan Harga Terbaik
Harga yang bagus QSFP56 200G Multi-mode 850nm 200G BASE-SR4 QSFP56 Transceiver on line

QSFP56 200G Multi-mode 850nm 200G BASE-SR4 QSFP56 Transceiver

Dapatkan Harga Terbaik
Hubungi Kami
Hubungi Sekarang
Deskripsi Produk
Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver With Diagnostic Monitoring
Feel free to contact us for details, compatibility, customization and wholesale pricing.

The QDD-400G-SR81 is a 8-Channel, Pluggable, Fiber-Optic QSFP-DD for 400Gbps SR8 Applications. It is a high performance module for short-range data communication and interconnect applications which operate at 53.125Gbps per lane up to 70m using OM3 fiber and 100m using OM4 fiber. The optical interface uses MPO receptacles.

This module is designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical interface uses a 76 contact edge type connector.

Key Features
  • Hot-pluggable QSFP-DD form factor
  • Data Rate 53.125 Gb/s PAM4 per lane
  • 8x53Gbps PAM4 transmitter and PAM4 receiver
  • 8 channels 850nm VCSEL laser array and 8 channels PIN photo-detector array
  • Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
  • Digital diagnostics functions are available via the I2C interface
  • Single 3.3V Power Supply and Power Dissipation < 12W
  • MPO-16 connector
  • Operating Case Temperature: 0℃~+70℃
  • RoHS compliant
Applications
  • 400G BASE-SR8 Ethernet
Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring 0 Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring 1 Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring 2 Hilink QDD-400G-SR8 Multi-mode 850nm 400G BASE-SR8 QSFP-DD Transceiver, With Diagnostic Monitoring 3
