Name: SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-SFP-BXU-L5/HL-SFP-BXD-L5
Price: 5.00 USD
Availability: InStock

Rumah > Produk > Modul Transceiver optik >

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Tempat asal:

Nama merek:

HiLink or OEM

Sertifikasi:

CE FCC ROSH

Nomor model:

HL-SFP-BXU-L5/HL-SFP-BXD-L5

Hubungi Kami

Minta Kutipan

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Rincian produk

Nama Produk:

Pemancar Optik SFP+ 10G BIDI 5KM

Kecepatan Data:

10 gram

Penularan:

5km

Tipe Konektor:

Panjang gelombang:

T1270/R1330

Kompatibel:

Cisco, Juniper, Arista, Huawei, dll

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 pasang

Harga

US$5.00~US$6.00/pair

Kemasan rincian

Paket Normal Atau OEM

Waktu pengiriman

5-8 hari kerja

Syarat-syarat pembayaran

T/T, PayPal, Western Union

Menyediakan kemampuan

2000 pasang per minggu

Produk terkait

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Dapatkan Harga Terbaik

10Gb/s XFP Bi-Directional Transceiver 40km Jangkauan TX1270/1330nm RX1330/1270nm RoHS Compliant

Dapatkan Harga Terbaik

Hilink 10G Data Rate SFP+ Transceiver dengan jarak 30M/80M dan RoHS Compliant 10GBASE-T Copper Module

Dapatkan Harga Terbaik

Hilink HL-SFP-T 1000BASE-T dan 10/100/1000BASE-T Copper SFP Transceiver dengan Konektor RJ-45

Dapatkan Harga Terbaik

Hubungi Kami

Hubungi Sekarang

Deskripsi Produk

Description

The HL-SFP-BXU-L5/HL-SFP-BXD-L5 Transceiver is intended for 5km reach service from 0.6Gb/s to 10.3125Gb/s BI-direction single mode high-speed communications equipment where low-cost, extraordinary performance and reliability are essential. It consumes low power, operates base on 3.3V DC power supply and is offered in the industrial temperature range. They are compliant with SFP28 MSA, SFF-8431 and SFF-8432.

The low jitter and low bit error rate optical assembly features a DML laser transmitter and PIN/TIA receiver. The differential AC coupled Tx and Rx data interfaces are CML compatible. The device is Class I laser safety compliant.

Product features

l Operating data rate up to 10.3125Gbps

l Up to 5km transmission distance

l High sensitivity PIN photodiode and TIA

l 12dB Power Budget at Least

l LC single connector

l Hot pluggable 20pin connector

l Low power consumption <1.2 W

l Single +3.3V±5% power supply

l Compliant with SFF-8472&SFF-8431

l Fully RoHS Compliant

l Compliant with IEEE802.3ae 10GBASE-LR/LW

l Operating temperature range:

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

Application

l 10GBASE-LR at 10.31Gbps

l 10GBASE-LW at 9.95Gbps

l Other Optical Links

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 0

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 1

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 2
